Zircon StudSensor EDGE

Description

The Zircon StudSensor™ EDGE stud finder finds the edges of wood and metal studs behind walls. The easy-to-read display and patented SpotLite® Pointer System clearly identify the edge of the target. The patented pivot pinch grip design allows for a comfortable, secure hold in either hand, at any angle.

• Locates the edges of wood or metal studs up to 3/4" (19 mm) deep
• “Ready” light indicates when calibration has completed successfully
• “Edge” light indicates when the tool is over a stud edge
• Patented SpotLite® Pointer shines an arrow-shaped beam on the wall to mark the target
• Zircon’s patented “over-the-stud” indication alerts user to start the scan in a new location if scanning begins over a stud
• Patented pivot pinch grip enables a comfortable hold in either hand, at any angle

Size 5.33"H x 2.14"W x 1.34"D
Weight 2.0 oz. (56.3 g) without battery
Position Wood studs: Typically within 1/8"
Accuracy* (3 mm) using the dual scan and mark procedure
Metal studs: Typically within 1/2" (13 mm) using the dual scan and mark procedure
Depth* Typically up to 3/4" (19 mm)
Operating Temperature 20° to 105°F (-7° to 41°C)
Storage Temperature -20° to 150°F (-29° to 66°C)
Humidity 5-90% RH (non-condensing)
Water Splash and water resistant, not Resistance waterproof

Requires 9V battery, sold separately.
