OSEPP 16 x 2 LCD Display & Keypad Shield

Description

The OSEPP 16 x 2 LCD Display and Keypad shield can plug directly onto the Arduino and Arduino compatible boards. The LCD panel displays characters in white with a blue backlight and can display up to two lines of 16 characters. The shield includes 6 momentary push button that can be used to implement a 5 buttons keypad including up, down, left, right and select function. The sixth push button brings out the Arduino’s reset button to the top of the shield.

The OSEPP 16 x 2 LCD Display and Keypad shield interfaces with the Arduino board using digital pin 4 to 10 and analog pin 0. The contrast can be adjusted via a trim pot and the backlight can be turn on and off. The shield is 5V compatible.

• Mate with Arduino and Arduino compatible boards
• Display up to 16 characters by 2 line
• Integrated the SPLC780D 16 COMs x 40 SEGs dot-matrix LCD controller and driver
• 5V operating voltage
• 5 button keypad – up, down, left, right, and select
• Brings out the Arduino’s reset button to the top of the shield

Qty.: 1
