Next Wave Shark HD510 CNC Machine

Description

The perfect tool for carving or machining projects made from wood, soft metals, composites, or plastics. Built with industrial-grade components, this machine features a heavy-duty aluminum and steel reinforced gantry, a new extruded aluminum router mount system, interlocking aluminum table, linear rails, and guides on the gantry, and anti-backlash, wear-compensated lead screws on all axis. Use Next Wave CNC’s exclusive, patented Virtual Zero Unlimited software to make and carve unique wooden creations. Manufacturer's 2-year warranty. Made in USA.

Table dimensions: 28" x 36"
XYZ travel: 25" x 25" x 7"
Overall dimensions: 36-1/4"W x 38"L x 24-1/2"H
Weight: 180 lbs.

Includes
Color Touch Screen pendant controller system
Virtual Zero Unlimited software
VCarve Desktop Design software
Ready2Control Basic software
Vector Art 3D Sampler Pack
olored touch screen pendant controller
Linear guides and bearings on the gantry
Anti-backlash, wear-compensated leadscrews on all axis
Interlocking rigid aluminum table with virtually unlimited clamp positioning
Aluminum gantry backplate for heavy machining capabilities.
Aluminum router mounting clamp
Steel encased gantry legs for increased rigidity
Automatic router on and off control
USB interface
2 hold-down clamps
carbide V-bit

Ships in 2 boxes.
Requires a PC Computer with a USB 2.0 port, not included.
Compatible with the following routers: Bosch 1617 and 1618, Porter-Cable 890 Series, DeWalt 610, 616, 618, any router with 3.5" motor diameter, sold separately.
