Miller Electric
Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.
Includes conventional Stick, DC TIG (Lift-ARC™ or HF Start), Flux-Cored, MIG, RMD®, and Pulsed MIG welding processes. These are optimized to deliver superior arc performance and stability, specifically for root pass, fill, and cap pipe welding.
Clearly labeled controls make it easy to set up a new weld process in just a few steps. Front panel features backlit controls only for adjustable settings to minimize confusion. Memory feature stores 4 programs for each selection: Stick, DC TIG, and MIG (left and right side of feeder).
No need to manually switch polarity or cables and hoses between processes. Simply push a process selection button to choose a welding process. PipeWorx 'Quick-Select' technology automatically selects the welding process, the correct polarity, cable outputs, and welding parameter.
Wind Tunnel Technology™ and Fan-On-Demand™ provide system protection in a dusty shop environment. Innovative cable and gun storage manages clutter for a cleaner, organized weld-cell area.
Manufacturer's 3-year warranty.
Processes: Regulated Metal Deposition (RMD)
Industries: Shipbuilding, Pipeline, Construction and Fabrication
Applications: Fabrication, Industrial Welding, Pressure Vessel, Process Pipe, Refineries and Power Plants, Education and Training
Weldable Metals: Specialty Metals, Stainless Steel, Steel
Amperage: 40 A - 400 A
Input Voltage: 220/230/240V, 460/480V
Rated Carbon Diameter: 5/16" (7.9 mm)
Input Phase: 3-Phase
Input: 50/60 Hz
Max Open Circuit Voltage: 90 VDC
Weld Output: CC/CV
Power Source size: 19.5"W x 31.75"D x 28.5"H
Dual Feeder size: 19"W x 29"D x 14"H
Weight: 501 lbs.
Includes
PipeWorx Dual Feeder with drive rolls
Two 15' PipeWorx 300A MIG Guns
Side-mount Cable Hangers
Cable Kit with 25' Work Sense Lead
Power Cord, Filler Metals, shielding gas, not included.
