Hobart Stickmate 160 Welder, 110-240V

Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.

Simple user interface with a single knob and digital display for distraction-free welding. Using DC output for stick welding means fewer arc outages, less sticking, less spatter, and better arc control. A wide amperage range provides easy adjustment for different materials and thicknesses. Operates on 120V or 240V power with included adapter - no tools needed. Lightweight and portable for easier carrying and storage.

Manufacturer's 5-year warranty on transformers, stabilizers, and main rectifiers; 3-year warranty on generators, PC boards, and drive systems; 1-year warranty on guns (MIG, plasma, and TIG torches).

Applications: Fabrication, Metal Art, Welding Projects
Weldable Metals: Aluminum, Stainless Steel, Steel
Current Type: DC
Rated Output: 120V 80 A @ 15% duty cycle, 240V 160A @ 15% duty cycle
Maximum Mild Steel Thickness: 1/8" (120V), 3/8" (240V)
Max Open Circuit Voltage: 95 VDC
Weld Output: 10-160A
Input Voltage: 110/115/120V, 220/230/240V
Input Phase: 1
Input Hz: 50/60 Hz
Size: 12.6"L x 6.3"W x 10.24"H
Weight: 10.6 lbs.

Includes
shoulder strap
10' electrode cable with heavy-duty holder
10' work cable with clamp
6.5' power cord with adapter for 120V and 240V
