ESAB
Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.
Manufacturer's 3-year warranty.
Primary Voltage: 120 VAC, 208/230 VAC
Supply Voltage Range: 90 – 270 VAC
Number of Phases: 1
Supply Frequency: 50/60 Hz
Supply Plug: 230 V, NEMA 6-50P
Lead Cord Length: 10'
Maximum Output: 250 A/30 V MIG (GMAW/FCAW) Welding Output @ 104°F (40°C) 120 A/19 V (120 V) @ 40% Duty Cycle. 235 A/26 V (230 V) @ 40% Duty Cycle. STICK (SMAW) Welding Output @ 104°F (40°C) 90 A/23.6 V (120 V) @ 40% Duty Cycle 210 A/28.4 V (230 V) @ 25% Duty Cycle. TIG (GTAW) Welding Output @ 104°F (40°C) 130 A/15.2 V (120 V) @ 40% Duty Cycle 240 A/19.6 V (230 V) @ 40% Duty Cycle.
Current Range: 5 – 150 A (120 V), 5 – 250 A (230 V)
MIG Welding Voltage Range: 10 – 30 V
Wire Feed Speed Range: 60 – 700 ipm (1.5 – 18 m/min)
Nominal OCV Volt/DC: 68 VDC
Maximum Plate Thickness: 1/2"
Wire Diameter Range: Mild Steel .023 – .035", Stainless Steel .030 – .035", Aluminum .030 – .045"
Wire Spool Size 4 in. (100 mm), 8 in. (200 mm), 12 in. (300 mm)
Approvals: CSA E60974-1-00, IEC 60974-1, UL60974-1
Protection Class: IP23S
Overall Size: 26.5"L x 11.5"W x 19.5"H
Weight: 63 lbs.
Includes
power supply
Tweco SprayMaster 250 MIG gun
regulator
12.5' hose
return clamp with leads
drive rolls
contact tips
wire
electrode holder
electrodes
power adapter
manual
