ESAB Cutmaster 40 Plasma Cutter, 110-240V

SKU: M405768 1-4000-1
Write a Review
$2,170.00
SKU:
M405768 1-4000-1
prop65:
sash:
NEW!
sashcolor:
#245E98

Frequently Bought Together

Please choose options for all selected products

Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.

Offering the highest power-to-weight ratio and cutting arc length in its class, this unit has a 40% duty cycle depending on application, automatic voltage input detection from 110-240 V, and will automatically set the max output: 27 amps for 110 and 40 amps for 200-240 V. Industrial SL60 1Torch with ATC® (Advanced Torch Connector).

  • Up to 1/2" (12 mm) recommended pierce and cut capacity with maximum sever of 1" (25 mm).
  • Cutmaster Black Series electrode included for up to 60% longer life of consumable parts.
  • Industry-leading 4-year warranty on power supply and 1-year warranty on torch.

Amperage Output: 15 – 40 A, continuously adjustable
Recommended Generator Size: 8.0 kW
Open Circuit Voltage: (OCV) 300 V
Input Voltage: 110 – 240 VAC +/- 10%, 50/60 Hz, 1ph
Rated Duty Cycle: 40% @ 40 A, 60% @ 30 A, 100% @ 20 A
Amperage Draw: 29 A @ 208 V, 26 A @ 230 V, 25.3A @115 V
Input Power Cable and Plug: 9' 1 ph 12 AWG 3/C with NEMA 6-50P plug
Work Lead with Ground Clamp: 13' #8 work cable with 50 mm connection
Gas Requirements: Compressed air
Operating Temperature Range: 32 – 122° F (0° – 50° C)
Operating Input Air Pressure Range: 90 – 125 psi (6.2 – 8.6 bar)
Min Air Flow Requirements cutting and gouging: 170 cfh (80 l/min)
Recommended Cut: up to 1/2 "
Maximum Sever: 1"
Pierce Rating: 1/2"
SL60 Torch Duty Cycle: 100% at 40 A @ 400 cfh (189 l/min)air flow
Overall size: 18.1"L x 7.9"W x 12.6"H
Weight: 22 lbs.

Includes
power supply
SL60 90° torch with lead
work lead with ground clamp
spare parts kit
input power adapters
1/4" NPT air fitting with quick connect
operating manual
