Edwards 55-Ton Ironworker with Powerlink, 5HP, 1PH

Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.

Plenty of power for large projects. The PowerLink™ System increases your capabilities by turning your Ironworker into a power source for Edwards' line of hydraulic tools. ETL/UL approved controls.

• Adjustable electric stoke control
• ANSI B11.5- 1988(02) compliant guarding
• Integrated emergency stop, lock-out/tag-out
• Optimized workstation heights for improved efficiency

Motor Amps: 23
Motor (HP): 5HP, 1PH, 230V
Motor Speed (RPM): 1,725
Angle Shear Max Capacity 1/2": 4 x 4
Angle Shear Max Capacity 1/4": 4 x 4
Angle Shear Max Capacity 3/8": 4 x 4
Angle Shear Work Height: 39-7/8"
Flat Bar Shear Max Capacity 1/2": 12
Flat Bar Shear Max Capacity 3/4": 4
Flat Bar Shear Max Capacity: 3/8" x 14", 1/2" x 12", 3/4" x 4"
Flat Bar Shear Max Round: 7/8"
Flat Bar Shear Max Square: 7/8"
Flat Bar Shear Rating (Tons): 55
Flat Bar Shear Work Height: 34-1/2"
Hydraulic Pump (GPM): 3-1/2
Hydraulics (GPM): 3-1/2
Hydraulics (PSI): 2,500
Open Station Open Height: 8-1/8"
Open Station Shut Height: 6-7/8"
Open Station Stroke: 1-1/4"
Open Station Throat Depth: 11-3/16"
Open Station Work Height: 34-1/2"
Open Workstation Throat Depth: 11-3/16"
Open Workstation Work Height: 34-1/2"
Punch Max Capacity: 1-1/16" dia. in 5/8" mild steel
Punch Open Height: 8-1/8"
Punch Rating (Tons): 55
Punch Shut Height: 6-7/8"
Punch Stroke: 1-1/4"
Punch Throat Depth: 7-1/2"
Punch Work Height: 36-9/16"
Rating (Tons): 55
Reservoir (Gal.): 7
Valve Pressure (PSI): 2,750
Overall Dimensions: 36-1/8"L x 44-3/8"W x 55-1/4"H
Gross Weight: 2,480 lbs.
