DOBOT MG400 Robotic Arm

Description

This lightweight desktop robot has a small footprint and was designed to be flexible to deploy, easy to use, and safe to collaborate. It features a 750g payload, 440mm maximum reach, hand-held teaching, and collision detection. It is equipped with servo motors with a high-precision absolute encoder, achieving a repeatability of ±0.05mm. With the vibration suppression algorithm deployed in the controller level, the repeatability bandwidth stabilization time is accelerated by 60%, and the residual vibration is reduced by 70%.

• Integrated and compact design is flexible and easy to set up. Just plug in and start working.
• Offers trajectory reproduction, graphical programming, and Lua script programming, which are ideal for applications of different complexity and varying programming skills.
• Intuitive programming interface and guided-interactive design greatly improve the programming efficiency and lower the threshold of robot applications.
• Supported by the robot dynamic gravity compensation algorithm, hand-held teaching is smooth, easy, and efficient.

Degree of Freedom: 4
Payload: 500g (Max 750g)
Reach: 440mm
Repeatability: ±0.05mm
Joint Ranges
J1: ±160°
J2: -25° ~ 85°
J3: -25° ~ 105°
J4 -180° ~ 180°
Joint Maximum Speed
J1: 300°/s
J2: 300°/s
J3: 300°/s
J4: 300°/s
Power: 100~240V AC, 50/60 Hz
Nominal Voltage: 48V
Nominal Power: 240W
Communication Interface: TCP/IP, Modbus TCP
Installation Way: Counter
Weight: 8kg
Base Size: 190mm × 190mm
Working Environment: 0 ℃ ~40 ℃
Software: DobotStudio 2020, SCStudio
