Dake Ratchet Lever Arbor Press, 3-Ton

Description

This arbor press has a ratchet lever that offers 3 tons of pressing capacity and can be used in any convenient position. The counterweight quickly returns the lever after each downstroke while the handwheel advances the ram to work quickly.

Capacity: 3 tons
Leverage ratio: 48:1
Ram size: 1-1/4" x 1-1/4" x 16-1/2"
Maximum diameter work: 14"
Throat: 7"
Largest arbor: 2"
Capacity over table: 11-1/2"
Capacity over table plate: 10-3/4"
Height: 18-1/2"
Weight: 125 lbs.

Includes
Cast Iron Base
Handwheel
Ram
Notched Table Plate
Counter weight
