Baileigh Hydraulic Box & Pan Brake, 220V, 5HP

Description

Designed with crowning compensation, the brake adjusts to fit the gauge you’re bending and produces uniform bends. Industrial-grade hydraulics will make precise and efficient bends. Hydraulic system clamps the material via dual hydraulic motors, then lifts the bending leaf with industrial hydraulic cylinders. Adjustable bend auto-stop simplifies production runs; just dial in your desired degree. Foot pedal and toggle joystick controls let you operate in manual or semiautomatic mode. Fully-welded steel beam and bending leaf, supported with truss rods, prevent twisting and deflection.

Manufacturer's 1-year warranty.

Style: Heavy Duty Hydraulic Box and Pan (Finger) Brake
Motor: 5 HP
Input Power: 220V / 3-phase
Beam Adjustment (Front to Rear): 1"
Bending Length Capacity: 96"
Maximum Box Depth: 6"
Mild Steel Capacity: 10 ga.
Max. Bend: 0 – 135°
Overall Length: 96"
Shipping Dimensions: 135"L x 44"W x 71"H
Weight: 5,640 lbs.

Includes
22 hardened 3-piece fingers (six 3", four 4", ten of 5" and two of 6")

Resources
