Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904 or email us at web@midwesttechnology.com.

A great metal lathe for anyone that is looking an economical lathe that is high in quality and features. Like all Baileigh Industrial lathes, the PL-1236E gear head metal lathe has an integrated gear system that allows for taping, turning and polishing with a range of speeds from 70 to 1,400 RPM. Lathe is built to last with only top quality components and all ways are ground and hardened to ensure long life.

  • 6" three jaw chuck
  • 8" four jaw chuck
  • Quick change tool holder
  • Foot brake
  • Coolant system with splash guard
  • Removable chip tray

Power: 220V, 1 phase, 1.5HP
Sleeve Travel: 4"
Spindle Bore: 1.50"
Spindle Bore Taper: Morse #5
Sleeve Taper: Morse #3
Sleeve Dia.: 1.25"
Range of Inch Threads: 4 - 56 TPI
Metric Thread Range: 0.4 – 7 mm
Spindle Nose: D1-4"
Travel Of Cross Slide: 5.312"
Travel Of Top Slide: 3.250"
Width Of Bed: 7.125"
Spindle Speed: 9 (70 – 1400 rpm)
Swing in Gap: 17"
Swing Over Bed: 12"
Swing Over Cross Slide: 7.625"
Longitudinal Feed Range: 0.002" – 0.0548"/rev
Lead Screw Thread Pitch: 8 TPI
Length of Gap: 6"
Max. Tool Selection: .625" x .625"
Cross Feed Range: 0.007" – 0.0187"/rev
Distance Between Centers: 36"
Tool weight: 1,232 lbs. (shipping)

Includes 3- and 4-jaw chucks, steady rest, follow rest, face plate, live center, foot brake, coolant system and halogen work light.
