Baileigh 1006846 Manual Roll Bender

Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.

Does almost everything larger rollbenders can. Maximum capacity of 1.25” (.078” wall) mild steel round tubing and 1” schedule 40 pipe capacity. Open-face design allows you to roll full circles. Manual drive includes reduction gearbox to cut down on physical effort. Hardened rolling shafts turn on bronze bushings, ensuring the machine will last for years and wear well.

• Various segment rolls for different types of flat bar, angle iron, and square tubing
• Cast steel head maintains accuracy when bending at full capacity
• Machine base opens to a handy storage cabinet
• Mfr.'s 1-year parts warranty plus lifetime technical support by phone

Roll Adjustment: Manual
Pipe Capacity: Size: 1" (sch. 40) / Min. Dia.: 28"
Round Tube Capacity: Size: 1.25" (.078") / Min. Dia.: 31.5"
Square Tube Capacity: Size: 1.25" (.078") / Min. Dia.: 35"
Solid Round Capacity: Size: .875" / Min. Dia. 20"
Flat Bar Easy Way: 1.96" (.39") / Min. Dia.: 15.75"
Flat Bar Hard Way: 1.18" (.39") / Min. Dia.: 19.685"
Angle Iron Capacity: Size: 1.25" (.157") / Min. Dia.: 30"
Shaft Diameter: 1.181"
Shaft Center Distance: 6.7"
Lower Roll Dia: 4.65"
Pinch: Single
Power: Manual
Material Type: All Specs based on 60,000 PSI (42 Kg/mm 2) Tensile Strength –Mild Steel
Shipping Dimensions: 31" x 25" x 39"
Shipping Weight: 460 lbs.
